■由于篇幅所限,下列型號僅是我廠生產的部分產品,客戶需要時請與公司技術部聯系。 ■The following bearings are only part of our products. If you need other products, Please make contact with our sales/technical department. |
調心滾子軸承 Spherical Roller Bearing
軸承型號 Designation |
外型尺寸 Principal Dimension |
額定負荷(kN) Basic Load Ratings |
極限轉速(r/min) Speed ratings |
質量 Mass | |||||
d | D | B | r min |
動負荷 Dynamic |
靜負荷 Static |
脂 Grease |
油 Oil |
kg | |
23032 | 160 | 240 | 60 | 2.1 | 376 | 730 | 1500 | 1900 | 13.5 |
24032CA | 160 | 240 | 80 | 2.1 | 636 | 1164 | 1100 | 1500 | 12.9 |
24132CA | 160 | 270 | 109 | 2.1 | 1010 | 1700 | 700 | 900 | 25.4 |
22232K | 160 | 290 | 80 | 3 | 805 | 660 | 1500 | 1900 | 23.5 |
22232/W33 | 160 | 290 | 80 | 3 | 658 | 1074 | 1350 | 1700 | 22.1 |
22332 | 160 | 340 | 114 | 4 | 1170 | 1730 | 800 | 1000 | 50.3 |
23034 | 170 | 260 | 67 | 2.1 | 450 | 900 | 1400 | 1800 | 14.7 |
23034K/W33 | 170 | 260 | 67 | 2.1 | 450 | 900 | 1400 | 1800 | 14.6 |
23034CA | 170 | 260 | 67 | 2.1 | 615 | 580 | 1600 | 2000 | 14.2 |
24034CA/W33 | 170 | 260 | 90 | 2.1 | 810 | 820 | 1000 | 1400 | 17.8 |
23134 | 170 | 280 | 88 | 2.1 | 875 | 805 | 1200 | 1600 | 23 |
23134K/W33 | 170 | 280 | 109 | 2.1 | 1050 | 1020 | 670 | 850 | 24.8 |
22234 | 170 | 310 | 86 | 4 | 730 | 1230 | 1100 | 1500 | 27.6 |
23234CA | 170 | 310 | 110 | 4 | 1160 | 1835 | 950 | 1300 | 37.1 |
22234CA | 170 | 310 | 86 | 4 | 970 | 820 | 1300 | 1700 | 26.8 |
22334K | 170 | 360 | 120 | 4 | 1200 | 2010 | 850 | 1200 | 59.8 |
23036 | 180 | 280 | 74 | 2.1 | 550 | 1100 | 1300 | 1600 | 19.5 |
23036K/W33 | 180 | 280 | 74 | 2.1 | 550 | 1100 | 1300 | 1600 | 19.3 |
24036 | 180 | 280 | 100 | 2.1 | 930 | 1510 | 850 | 1200 | 22.5 |
23136 | 180 | 300 | 96 | 3 | 700 | 1340 | 990 | 1400 | 27.1 |
23136N | 180 | 300 | 96 | 3 | 700 | 1340 | 990 | 1400 | 26.4 |
24136CA/W33 | 180 | 300 | 118 | 3 | 1170 | 1130 | 630 | 800 | 33 |
22236 | 180 | 320 | 86 | 4 | 750 | 1300 | 1200 | 1500 | 28.6 |
23236CA | 180 | 320 | 112 | 4 | 1250 | 2060 | 900 | 1200 | 39.6 |
22236CA/W33 | 180 | 320 | 86 | 4 | 1030 | 880 | 1300 | 1700 | 29.4 |
22336 | 180 | 380 | 126 | 4 | 1430 | 2210 | 800 | 1100 | 80.7 |
2638 | 190 | 280 | 67 | 2.5 | 542 | 978 | 1200 | 1500 | 13.7 |
23038K | 190 | 290 | 75 | 2.1 | 626 | 1100 | 1200 | 1500 | 20.5 |
23038CA | 190 | 290 | 75 | 2.1 | 765 | 735 | 1300 | 1700 | 16.9 |
24038CA | 190 | 290 | 100 | 2.1 | 980 | 1000 | 950 | 1300 | 22.8 |
22238CAK | 190 | 340 | 92 | 4 | 1070 | 1650 | 1200 | 1600 | 36 |
23238CA | 190 | 340 | 120 | 4 | 1410 | 2300 | 850 | 1100 | 51 |
22338 | 190 | 400 | 132 | 5 | 1400 | 2440 | 760 | 1000 | 80.6 |
23040 | 200 | 310 | 82 | 2.1 | 655 | 1170 | 1100 | 1400 | 26.2 |
24040CA | 200 | 310 | 109 | 2.1 | 1130 | 1170 | 900 | 1200 | 31.3 |
23140 | 200 | 340 | 112 | 3 | 930 | 1830 | 850 | 1200 | 50.9 |
24040CA | 200 | 340 | 112 | 3 | 1350 | 1260 | 950 | 1300 | 43.6 |
24140CK30 | 200 | 340 | 140 | 3 | 1530 | 2700 | 560 | 700 | 52 |
22240 | 200 | 360 | 98 | 4 | 940 | 1630 | 1000 | 1400 | 44.7 |
22240CA/W33 | 200 | 360 | 98 | 4 | 1270 | 1110 | 1100 | 1500 | 44.5 |
22340K | 200 | 420 | 138 | 5 | 1880 | 1620 | 850 | 1100 | 96 |
22340 | 200 | 420 | 138 | 5 | 1880 | 1620 | 850 | 1100 | 96 |
2644 | 220 | 320 | 76 | 3 | 758 | 1280 | 1000 | 1300 | 21.6 |
23044 | 220 | 340 | 90 | 3 | 960 | 990 | 1100 | 1500 | 28.8 |
23044CA | 220 | 340 | 118 | 3 | 1070 | 1040 | 1100 | 1500 | 32 |
24044CA | 220 | 340 | 118 | 3 | 1320 | 1370 | 850 | 1100 | 39 |
23144 | 220 | 370 | 120 | 4 | 1330 | 1330 | 900 | 1200 | 54.8 |
23144CA | 220 | 370 | 120 | 4 | 1570 | 1520 | 900 | 1200 | 54.7 |
23144K | 220 | 370 | 120 | 4 | 1330 | 1330 | 900 | 1200 | 54.8 |
22244 | 220 | 400 | 108 | 4 | 1200 | 2100 | 850 | 1200 | 57.6 |
23244 | 220 | 400 | 144 | 4 | 1800 | 2820 | 670 | 850 | 94.6 |
22344/W33 | 220 | 460 | 145 | 5 | 1700 | 3090 | 670 | 850 | 129 |
23948CA | 240 | 320 | 60 | 2.1 | 635 | 710 | 1300 | 1700 | 14.9 |
23048 | 240 | 360 | 92 | 3 | 820 | 1800 | 900 | 1200 | 37.6 |
23048K/W33 | 240 | 360 | 92 | 3 | 820 | 1800 | 900 | 1200 | 37.4 |
23148 | 240 | 400 | 128 | 4 | 1200 | 2560 | 760 | 990 | 77.2 |
24148/W33 | 240 | 400 | 160 | 4 | 1200 | 3300 | 430 | 540 | 81.6 |
24148CAK30/W33 | 240 | 400 | 160 | 4 | 2020 | 2040 | 480 | 600 | 77.8 |
22248 | 240 | 440 | 120 | 4 | 1490 | 2370 | 800 | 1000 | 85 |
23248 | 240 | 440 | 160 | 4 | 2200 | 3460 | 600 | 760 | 128 |
22348K | 240 | 500 | 155 | 5 | 1780 | 3140 | 600 | 760 | 154 |
22348K/W33 | 240 | 500 | 155 | 5 | 1780 | 3140 | 600 | 760 | 153 |
2650 | 250 | 365 | 87 | 3 | 950 | 1650 | 880 | 1100 | 32.2 |
23052K | 260 | 400 | 104 | 4 | 1000 | 2180 | 810 | 1080 | 51.5 |
24052CA | 260 | 400 | 1400 | 4 | 1780 | 1910 | 700 | 900 | 66.7 |
24052CAK/W33 | 260 | 400 | 140 | 4 | 1780 | 1910 | 700 | 900 | 65.2 |
23152 | 260 | 440 | 144 | 4 | 1950 | 2010 | 800 | 1000 | 92.8 |
23252CA/W33 | 260 | 480 | 174 | 5 | 2780 | 2660 | 630 | 800 | 147 |
22352 | 260 | 540 | 165 | 6 | 2840 | 2550 | 630 | 800 | 191.3 |
23056K | 280 | 420 | 106 | 4 | 1100 | 2380 | 760 | 950 | 62 |
24056CA | 280 | 420 | 140 | 4 | 2140 | 2410 | 670 | 850 | 69.2 |
23156CA | 280 | 460 | 146 | 5 | 2300 | 2310 | 750 | 950 | 105 |
23156 | 280 | 460 | 146 | 5 | 1790 | 3300 | 670 | 850 | 95.5 |
22236CA/W33 | 280 | 500 | 130 | 5 | 2020 | 1800 | 750 | 950 | 118 |
23256 | 280 | 500 | 176 | 5 | 2470 | 4550 | 540 | 670 | 153 |
23256CA | 280 | 500 | 176 | 5 | 2970 | 2910 | 600 | 750 | 147 |
22356 | 280 | 580 | 175 | 6 | 2680 | 4490 | 540 | 670 | 238 |
22356K/W33 | 280 | 580 | 175 | 6 | 2680 | 4490 | 540 | 670 | 238 |
23960CA/W33 | 300 | 420 | 90 | 3 | 1190 | 1320 | 950 | 1300 | 40.5 |
23060 | 300 | 460 | 118 | 4 | 1430 | 2740 | 720 | 900 | 75.2 |
24060CA/W33 | 300 | 460 | 160 | 4 | 2280 | 4600 | 540 | 670 | 101 |
23060CA/W33 | 300 | 460 | 118 | 4 | 1830 | 1880 | 800 | 1000 | 71.5 |
23160 | 300 | 500 | 160 | 5 | 2180 | 4030 | 600 | 760 | 134 |
24160CA/W33 | 300 | 500 | 200 | 5 | 3180 | 6100 | 324 | 400 | 159 |
22260CA | 300 | 540 | 140 | 5 | 2620 | 2380 | 750 | 950 | 136 |
23260CA/W33 | 300 | 540 | 192 | 5 | 3300 | 3250 | 530 | 670 | 190 |
22260 | 300 | 540 | 140 | 5 | 2070 | 3250 | 670 | 850 | 143 |
23964K | 320 | 440 | 90 | 3 | 1200 | 2210 | 600 | 750 | 45.1 |
23064K | 320 | 480 | 121 | 4 | 1400 | 2920 | 720 | 900 | 81.5 |
24064CA | 320 | 480 | 160 | 4 | 2380 | 2620 | 700 | 900 | 106 |
23164CAK | 320 | 540 | 176 | 5 | 3150 | 3200 | 630 | 800 | 195 |
23264CA | 320 | 580 | 208 | 5 | 3900 | 3900 | 500 | 630 | 251 |
23264CAK/W33 | 320 | 580 | 208 | 5 | 3900 | 3900 | 500 | 630 | 251 |
23968 | 340 | 460 | 90 | 3 | 1260 | 2360 | 810 | 1050 | 50.5 |
23068K | 340 | 520 | 133 | 5 | 1620 | 3400 | 630 | 810 | 109 |
23068/W33 | 340 | 520 | 133 | 5 | 1620 | 3400 | 630 | 810 | 109 |
23068CA | 340 | 520 | 133 | 5 | 2280 | 2390 | 700 | 900 | 114 |
23068CAK | 340 | 520 | 133 | 5 | 2280 | 2390 | 700 | 900 | 111 |
24068CAK30 | 340 | 520 | 180 | 5 | 2870 | 3200 | 530 | 670 | 135 |
24068/W33 | 340 | 520 | 180 | 5 | 2436 | 5060 | 470 | 600 | 160 |
23972 | 360 | 480 | 90 | 3 | 1330 | 2510 | 760 | 990 | 49.1 |
23972CA | 360 | 480 | 90 | 3 | 1700 | 1730 | 850 | 1100 | 46.6 |
23072 | 360 | 540 | 134 | 5 | 1750 | 3730 | 600 | 760 | 114 |
23072CA | 360 | 540 | 134 | 5 | 2390 | 2530 | 670 | 850 | 126 |
24072CA/W33 | 360 | 540 | 180 | 5 | 3010 | 6350 | 500 | 630 | 148 |
23172K | 360 | 600 | 192 | 5 | 2400 | 5350 | 500 | 630 | 222 |
24172 | 360 | 600 | 243 | 5 | 4300 | 7330 | 270 | 340 | 333 |
22372 | 360 | 750 | 224 | 7.5 | 4180 | 7500 | 280 | 360 | 494 |
22372CA | 360 | 750 | 224 | 7.5 | 5400 | 4900 | 400 | 500 | 466 |
23976 | 380 | 520 | 106 | 4 | 1410 | 2670 | 720 | 900 | 73.5 |
23976CA/W33 | 380 | 520 | 106 | 4 | 1750 | 2100 | 800 | 1000 | 69.5 |
23076K | 380 | 560 | 135 | 5 | 1750 | 3780 | 560 | 720 | 122 |
23076CA | 380 | 560 | 135 | 5 | 2440 | 2690 | 630 | 800 | 130 |
24176CAK30/W33 | 380 | 560 | 180 | 5 | 3050 | 3550 | 190 | 260 | 153 |
23176 | 380 | 620 | 194 | 5 | 2680 | 5680 | 360 | 450 | 244 |
23176CA/W33 | 380 | 620 | 194 | 5 | 3900 | 4100 | 400 | 500 | 248 |
23176CAK/W33 | 380 | 620 | 194 | 5 | 3900 | 4100 | 400 | 500 | 241 |
23980CA/W33 | 400 | 540 | 106 | 4 | 1790 | 2160 | 750 | 950 | 72.4 |
2680 | 400 | 590 | 142 | 6 | 2290 | 4420 | 340 | 530 | 145 |
23080 | 400 | 600 | 148 | 5 | 2100 | 4570 | 540 | 670 | 165 |
23080CA | 400 | 600 | 148 | 5 | 2820 | 3000 | 600 | 750 | 158 |
24080CA/W33 | 400 | 600 | 200 | 5 | 2840 | 3050 | 450 | 560 | 202 |
23180 | 400 | 650 | 200 | 6 | 3060 | 6670 | 340 | 430 | 239 |
23180CA | 400 | 650 | 200 | 6 | 4100 | 4300 | 380 | 480 | 272 |
23280 | 400 | 720 | 256 | 6 | 5750 | 8420 | 310 | 390 | 530 |
22380 | 400 | 820 | 243 | 7.5 | 4650 | 8960 | 240 | 320 | 650 |
23084 | 420 | 620 | 150 | 5 | 2320 | 4570 | 400 | 500 | 159 |
23084CA | 420 | 620 | 150 | 5 | 2970 | 3300 | 450 | 560 | 149 |
23184/W33 | 420 | 700 | 224 | 6 | 4170 | 8100 | 320 | 400 | 402 |
23284CA | 420 | 760 | 272 | 7.5 | 6140 | 11250 | 320 | 400 | 659 |
23088 | 440 | 650 | 157 | 6 | 2450 | 5120 | 390 | 480 | 192 |
23188 | 440 | 720 | 226 | 6 | 4910 | 8710 | 310 | 390 | 420 |
23188/W33 | 440 | 720 | 226 | 6 | 4910 | 8710 | 310 | 390 | 419 |
23092 | 460 | 680 | 163 | 6 | 2520 | 5880 | 360 | 450 | 223 |
23092CA | 460 | 680 | 163 | 6 | 3550 | 3850 | 400 | 500 | 226 |
23192CA | 460 | 760 | 240 | 7.5 | 5750 | 6200 | 320 | 400 | 457 |
23192CAK/W33 | 460 | 760 | 240 | 7.5 | 5750 | 6200 | 320 | 400 | 452 |
23996 | 480 | 650 | 128 | 5 | 2240 | 4730 | 360 | 450 | 162 |
23096 | 480 | 700 | 165 | 6 | 2500 | 5730 | 340 | 430 | 231 |
23196CAK/W33 | 480 | 790 | 248 | 7.5 | 6150 | 6700 | 300 | 380 | 485 |
23296 | 480 | 870 | 310 | 7.5 | 6900 | 11500 | 230 | 310 | 837 |
239/500 | 500 | 670 | 128 | 5 | 2100 | 5020 | 360 | 450 | 135 |
239/500CA | 500 | 670 | 128 | 5 | 2570 | 3200 | 400 | 500 | 120 |
230/500 | 500 | 720 | 167 | 6 | 3050 | 6400 | 340 | 430 | 238 |
230/500/W33 | 500 | 720 | 167 | 6 | 3050 | 6400 | 340 | 430 | 238 |
230/530 | 530 | 780 | 185 | 6 | 3590 | 7500 | 310 | 390 | 313 |
230/530CA | 530 | 780 | 185 | 6 | 4500 | 5200 | 340 | 430 | 335 |
230/530/W33 | 530 | 780 | 185 | 6 | 3590 | 7500 | 310 | 390 | 314 |
239/560CA | 560 | 750 | 140 | 5 | 3150 | 4000 | 340 | 430 | 177 |
230/560 | 560 | 820 | 195 | 6 | 3930 | 8870 | 230 | 310 | 367 |
230/560K | 560 | 820 | 195 | 6 | 3930 | 8870 | 230 | 310 | 367 |
230/560/W33 | 560 | 820 | 195 | 6 | 3930 | 8870 | 230 | 310 | 365 |
231/560/W33 | 560 | 920 | 280 | 7.5 | 7990 | 16000 | 240 | 320 | 757 |
230/600 | 600 | 870 | 200 | 6 | 4240 | 9310 | 270 | 340 | 417 |
230/600CAK | 600 | 870 | 200 | 6 | 5350 | 6300 | 300 | 380 | 430 |
230/600K/W33 | 600 | 870 | 200 | 6 | 4240 | 9316 | 270 | 340 | 393 |
241/600 | 600 | 980 | 375 | 7.5 | 8960 | 19600 | 110 | 150 | 1079 |
230/630 | 630 | 920 | 212 | 7.5 | 4700 | 10200 | 230 | 300 | 511 |
230/630/W33 | 630 | 920 | 212 | 7.5 | 4700 | 10200 | 230 | 300 | 509 |
239/670/W33 | 670 | 900 | 170 | 6 | 4020 | 8560 | 230 | 300 | 317 |
230/670 | 670 | 980 | 230 | 7.5 | 5170 | 8560 | 220 | 290 | 657 |
230/670/W33 | 670 | 980 | 230 | 7.5 | 5170 | 8560 | 220 | 290 | 655 |
239/710 | 710 | 950 | 180 | 6 | 4050 | 8810 | 220 | 290 | 389 |
239/710/W33 | 710 | 950 | 180 | 6 | 4050 | 8810 | 220 | 290 | 387 |
230/710/W33 | 710 | 1030 | 236 | 7.5 | 5790 | 13100 | 200 | 27 | 742 |
241/710/W33 | 710 | 1150 | 438 | 9.5 | 11730 | 29940 | 90 | 120 | 1802 |
249/800/W33 | 800 | 1060 | 258 | 6 | 6240 | 15200 | 1700 | 230 | 638 |
230/800/W33 | 800 | 1150 | 258 | 7.5 | 8630 | 20000 | 190 | 200 | 986 |
240/800 | 800 | 1150 | 345 | 7.5 | 10300 | 13200 | 120 | 160 | 1092 |
240/900/W33 | 900 | 1280 | 375 | 7.5 | 11000 | 28000 | 130 | 170 | 1783 |
240/1000/W33 | 1000 | 1420 | 412 | 7.5 | 13300 | 40000 | 120 | 160 | 2117 |
廠址:洛陽高新技術開發區洛宜南路科技園A-4-413 公司地址:中國河南省洛陽市龍門大道86號 (471003) 銷售部電話:0379-63753082 13015551139 13525400490 外貿部電話:0086-379-63753082 0086-13015551139 傳真:0086-379 - 65512003 技術服務電話:0379 - 63753082 E-mail:lypbearing@163.com MSN: lypbearing@hotmail.com QQ: 251725885 593272943 |
ADD:No.A-4-413, luoyi south Road, Luoyang, Henan Province, China TEL:0086-379-63753082 0086-13015551139 0086-13525400490 FAX:0086-379-65512003 POSTCODE: 471003 E-mail:lypbearing@126.com<mailto:lypbearing@163.com> MSN :lypbearing@hotmail.com |
